Ultrakompakt medico-grade 6W AC/DC-konverter
Med dimensioner på kun 1"x1" sætter RECOM ny rekord for den mest kompakte 6W boardmonterbare AC/DC-konverter, der kan bruges i mange sammenhænge - herunder medico-produkter (in english).
The RACM06E-K/277, a market-leading, board-mount, through-hole 6W AC/DC converter has been launched by RECOM, with performance that makes it ideal for a wide range of applications. Input nominal voltages are 100-277VAC (80-305VAC, 120-430VDC) for worldwide use, and isolation is reinforced/2MOPP for any application, from household to patient-connect medical.
A range of outputs is available: 3.3V, 5V, 12V, 15V, and 24V, and high efficiency, maintained down to light loads, enables operation from -40°C to 90°C ambient with a full load rating up to 60°C.
Full protection is provided against over-temperature, output short-circuits, and over-voltage.
Safety certifications include IT/multimedia, medical, industrial, and household, and ‘Class B’ EMC specifications are met with good margin with a ‘floating’ load.
For medical use, touch current is less than 0.1mA for ‘body-floating’ patient-connect applications and no-load dissipation is 120mW maximum for compliance with eco-design requirements.
The RACM06E-K/277 is characterized for operation to 5000m altitude in over-voltage category II (OVC II) environments to IEC/EN 62368-1 and to 3000m for OVC III according to IEC 61558-2-16. The part is encapsulated with a plastic casing, the case size is 25.6 x 25.6 x 16.6mm and the weight is just 20 grams.
- We have managed to pack outstanding performance into this tiny AC/DC. It can be used in practically any application – and it is economical too, comments Michael Schrutka, AC/DC product manager of RECOM.
Parts include a three-year warranty and samples, and OEM pricing is available from all authorized distributors, or directly from RECOM.
