Referencedesign for 240W USB PD3.1 løsning
Arrow Electronics og Infineon Technologies introducerer 240W USB PD3.1 referencedesign, der understøtter op til 48V@5A 'Power Delivery Object' sink mode, som er det højeste mulige med de seneste USB Power Delivery standarder (in english).
Arrow Electronics and Infineon Technologies AG have introduced the 240W USB Power Delivery (PD) 3.1 reference design board to support customer projects requiring high power capabilities. The new design demonstrates the USB PD 3.1 Extended Power Range (EPR) software and schematics implementation example allowing to achieve up to 240W power sink from a single USB source.
The reference design further extends existing power sink capabilities of Infineon’s EZ-PDTM PMG1 family of high-voltage microcontrollers from 140W up to 240W, which is important in such power-demanding and fast-charging applications as: light electric vehicles (eBikes, eScooters and personal mobility devices), drones and mobile robots, professional AV equipment, power tools, medical equipment, home appliances, home entertainment devices, etc.
This 240W Sink reference design board REF_ARIF240WS3 complements the recently released Infineon USB PD3.1 Source evaluation board REF_XDPS2222_240W1. This allows design engineers to be among the first on the market with the complete 240W USB PD3.1 Source-Sink solution.
Both reference designs are available on request. In addition to technical support, Arrow offers a range of technical support services, including schematic customization and PCB modifications, helping to maximize the potential of customers' designs and reduce time-to-market.
