Komplet power management-løsning til energy harvesting
SiliconReef - der er repræsenteret gennem Texim Europe - står bag power management løsning til brug i en bred vifte af energy harvesting baserede applikationer (in english).
he EH01 from SiliconReef is a complete power management solution for a variety of energy-harvesting applications based on a DC/DC converter concept. This device provides a small and simple solution combining power from different sources: a DC wall adapter, photovoltaic cells and a Li-Ion battery.Using a high efficiency DC/DC converter the EH01 converts the voltage from the solar panel to a stable 5V output. In addition a Li-Ion Battery Charger (with numerous protection features) stores the excess energy from the panel in an external battery. This battery then complements the energy to the DC/DC converter when needed.
There are two ways of monitoring the battery status. You can simply push the button making a LED pulse or you can use a microcontroller based serial communication. This device enables a simple implementation of a 5V supply, like a USB charger compatible with the ITU standard for the Universal Charging Solution.
To help you designing your EH01 application SiliconReef provides three different evaluation kits.
Main features includes:
• Complete all-in-one management of energy-harvesting process
• Works with both solar panels or conventional wall adapters
• Regulated 5V output power port withstanding currents up to 1.2A
• Operation mode consumption below 5mW
• Total conversion efficiency above 90%
• Stand-by consumption less than 500uW
• Battery monitoring via LED or serial interface
Applications:
• Solar battery chargers
• Mobile devices powered by solar energy
• Solar powered wireless sensor nodes
• Automotive parts
• Utilities
• Electronic equipment
• Industrial applications
