Ny USB Type-C til HDMI/DVI/VGA adapter-dongle

Cypress introducerer ny USB Type-C til HDMI/DVI/VGA adapter-dongle løsning samt et robust USB Type-C udviklingskit (in english).

Additionally, Cypress further expanded its USB-Type C design support with the new CY4501 CCG1 Development Kit (DVK), which enables designers to add USB Type-C to any system.

The Cypress USB Type-C to HDMI/DVI/VGA solution includes USB Billboard functionality, which allows the adapter to communicate status to a host that does not support DisplayPort (DP). This solution uses Cypress’s EZ-PD CCG1 (CYPD1120) USB Type-C Port Controller to support DP as one of its Alternate Modes, Cypress’s USB Billboard controller (CY7C65210) to support the USB Billboard Device Class, and MegaChips’ DP to HDMI/DVI/VGA protocol convertor chip.

Cypress has demonstrated that its USB Type-C to HDMI solution with power delivery (PD) is interoperable with the Apple MacBook, the Google Chromebook Pixel and multiple other systems at USB-PD Interoperability events.

- With the rapid adoption of USB Type-C, the market is looking for fast ways to bring USB Type-C connectivity to products and for adapter dongles that enable connectivity with older products, says Ganesh Subramaniam, Senior Director of the USB product line at Cypress.

- Cypress's CY4501 CCG1 Development Kit demonstrates the ability of our EZ-PD CCG1 controllers to serve as a total USB Type-C solution by packaging the host, client and cable boards in a single kit for unmatched ease of implementation. Likewise, we designed our complete EZ-PD CCG1-based USB Type-C to HDMI/DVI/VGA Adapter solution to help customers get their dongles to market quickly.

Cypress customers can pre-order the new CY4501 CCG1 DVK online from the Cypress store. Based on Cypress’s EZ-PD CCG1 USB Type-C Port Controller, the kit serves as a platform to evaluate several features for USB Type-C with design examples and demonstrations of USB SuperSpeed, DisplayPort and Power Delivery.

The CY4501 CCG1 DVK includes a CCG1 host board that emulates a tablet or a notebook, a CCG1 client board that emulates a monitor or a docking port, and a CCG1 Electronically Marked Cable Assembly (EMCA) board emulating a USB Type-C cable.

The USB Type-C standard is gaining rapid support with top-tier PC makers by enabling slim industrial designs, easy-to-use connectors and cables, the ability to transmit multiple protocols, and 100W power delivery (PD)—a significant improvement over the previous 7.5W standard.

The USB Type-C standard’s 2.4-mm-high connector plug is significantly smaller than current 4.5-mm USB Type-A standard connectors. It also allows for transport of USB signals and PCIe or DP signals on the same connector. A CCG1 product video, which demonstrates the transmission of DisplayPort signals over a USB Type-C connection, is available at www.cypress.com/ccg1video
