30.7 cm TFT display med bred betragtningsvinkel
MSC Technologies kan nu levere Innolux' nye 30.7 cm (12.1‘) wide-angle TFT display (in english)
MSC Technologies, a company of Avnet, has included the new Innolux G121XCE-L01 30.7 cm (12.1‘) TFT display in its product range. The display supports XGA resolution with 1024 x 768 pixels, and can display 252k/16.2M colors. The integrated MVA (Multi Vertical Alignment) technology allows viewing angles of 89 degrees from all directions.The TFT display features a LED backlight with an integrated LED driver. The manufacturer specifies a service life of at least 50,000 hours for the backlight, though typically extending even to 70,000 hours. The display's luminance is 600 cd/m². Its contrast ratio is 1000:1.
With a broad operating temperature range from -30 °C to +85 °C, the G121XCE-L01 is fully capable of handling industrial applications, and is also suitable for use in harsh environments. Potential industrial applications include automation, medical technology, transportation, POS, and infotainment. The display unit's surface is protected by an anti-glare coating with a hardness of 3H.
The robust display features a standard 6/8 bit LVDS port. The unit's active display area is 245.8 x 184.3 mm, with outer dimensions of 249.0 x 187.5 mm.
Innolux specifies a minimum availability of five years from start of production for industrial display units. Sample quantities of the G121XCE-L01 model are available ex stock from MSC Technologies.
