Komponent-løsning til den næste generation af højhastigheds systemer
Texas Instruments lancerer 4GSPS, 12-bit A/D konverter samt bredbånds 15GHz PLL med integreret VCO (in english).
Texas Instruments (TI) has introduced an analog-to-digital converter (ADC) and phase-locked loop (PLL) with an integrated voltage-controlled oscillator (VCO) that deliver the widest bandwidth, lowest phase noise and highest dynamic range in the industry. The wideband ADC12DJ3200 is the fastest 12-bit ADC, delivering speeds up to 6.4 GSPS, according to Ti. The LMX2594 is the industry’s first wideband PLL solution to generate frequencies of up to 15 GHz without using an internal frequency doubler.High-density phased-array radar systems, 5G systems and satellite communications demand increased data throughput, higher bandwidth and lower power, all in smaller a footprint. A multi-node synchronization reference design demonstrates how the
ADC12DJ3200 and LMX2594 provide accurate, time-stable synchronization for multi-node sampling systems including large-scale phased-array radars, digital storage oscilloscopes (DSOs) and 5G wireless testers. The reference design showcases the LMX2594’s SYSREF forwarding feature and the ADC12DJ3200’s aperture delay adjust, time stamp and calibration features to improve accuracy and ease system design
