ASIC-prototyping med Virtex-7 FPGA'er

Aldec gør sin entre på markedet for ASIC-prototyping med HES-7 platformen (in english).

Aldec Europe has announced the immediate availability of HES-7, an FPGA-based ASIC/SoC prototyping system that provides hardware verification and software verification teams with a versatile solution; and which lowers the cost of the prototyping process.

HES-7 takes full advantage of the Xilinx Virtex-7 2000T 3D IC, which affords a design capacity of up to 24 million ASIC gates on a single, dual-device HES-7 board. In addition, the system employs a non-proprietary high-speed backplane connector that enables easy expansion of custom daughter boards or which can facilitate the connection of up to four HES-7 boards, delivering a total design capacity of up to 96 million ASIC gates.

Zibi Zalewski, Hardware Division General Manager at Aldec, comments:
- Prototyping is beneficial to the whole ASIC delivery process, and the most common way to prototype is to use FPGAs.

- However, with most ASIC designs being between 10 and 20 million gates, to date it has been necessary to employ several low-density FPGAs on a single prototyping board; and implementing the SoC/ASIC design has been a painful and costly process because the design needs to be partitioned between the multiple devices. Using a dual-chip HES-7 prototyping solution from Aldec, equipped with Xilinx’s industry-leading Virtex-7 2000T devices, reduces the design implementation effort and lowers the tool expense when supporting multi-million gate SoC designs.

Kirk Saban, Sr. Product Line Manager, Virtex-7 Xilinx, adds:
- The HES-7 product fully leverages the power of our Virtex-7 2000T devices and our Vivado™ Design Suite, which together offer a strong combination of technology that accelerates time-to-validation and drives down the cost of the ASIC prototype process.

HES-7 is available in four different board configurations, which afford capacities of between 4 and 96 million ASIC gates.
www.aldec.com/products/HES-7.
